Extend wheel life by reducing chipping in chamfering of curved cover glass

[Issue]
With the electrification of automobiles, in-vehicle monitors are increasingly being used on instrument panels in addition to car navigation systems. Monitors for instrument panels often require cover glass with a curved surface, especially in high-end vehicles, to emphasize design. The long life of the chamfering wheels is required to reduce the machining cost of these cover glasses.


[Solution]
Our electroplated mounted wheels for chamfering reduce chipping even when the amount of glass to be machined increases by optimizing the shape of the abrasive grains, etc., thereby extending the life of the wheel.


For the chamfering of flat glass, the metal bond chamfering wheel contributes to more efficient machining by realizing high-precision form grinding with long-lasting sharpness and long life.

Extend wheel life by reducing chipping in chamfering of curved cover glass 画像 Extend wheel life by reducing chipping in chamfering of curved cover glass 画像
  • Comparison of the number of chamfering glasses with conventional products

    Comparison of the number of chamfering glasses with conventional products 画像
  • Processing condition

    Machine: Grinding center

    Material thickness: 0.55mm

    Wheel grain size: #1500

    .

    * Life decision : The number of holing & chamfering glasses to reach occurring over 20um chipping


Applicable tool

Electroplated mounted wheel for chamfering glass


We can also suggest how to control the amount of abrasive grains embedded and how to further increase the service life.

* The left photograph shows a general image of an electroplated mounted wheel for chamfering, but the tools used in the above process are different shape.
